Fume Hoods
Fume Hood Systems
High-performance ducted fume hood with aerodynamic sash and advanced airflow technology. Features a stable, non-adjustable, removable baffle system with three fixed horizontal slots for optimal safety.
Key Features
Stable, non-adjustable Baffle System
Three fixed horizontal slots
Rain hood with rigid FRP pipe
Porcelain Sink with single way tap
Separate valves for utilities
5 Years Manufacturing Warranty
4-6 Weeks Delivery
Trusted by leading Indian pharmaceutical companies
Client
Medopharm
Chemical Research Division
Client
Caplin Point Labs
QC Laboratories
Client
Apex Labs
R&D Facilities
Client
State Government
Pharmaceutical Units
Technical Specifications
BafflesStable, non-adjustable, removable baffle system with three fixed horizontal slots
Duct200mm diameter, 4mm thick rigid FRP pipe, 10" height with rain hood
Bottom Arrangement3-feet height table made of 18 SWG Electro-Galvanized Sheet
StorageTop drawer, dummy drawer, bottom cupboard with horizontal partition
ConstructionAll locking arrangements, epoxy paint interior
Work SurfaceBlack Granite (20mm thickness)
AmenitiesPorcelain Sink (12" x 10") with single way water tap
ElectricalTwo 15/5 Amps 3-pin sockets, bush type starter, indicator lamp, 4-feet tube light
UtilitiesSeparate valves for Air, Vacuum, Nitrogen and Dampers
Ideal Applications
1
Chemical Research2
Pharmaceutical Labs3
Quality Control4
Educational Labs
